CYBERPOWER UPS OLS1000EA MainStream OnLine torony szünetmentes tápegység, kettős konverzió

CYBERPOWER UPS OLS1000EA MainStream OnLine torony szünetmentes tápegység, kettős konverzió

Name: CYBERPOWER UPS OLS1000EA MainStream OnLine torony szünetmentes tápegység, kettős konverzió
Brand: CYBERPOWER
SKU: WINTER-IT-299202
Price: 2255.24 PLN
Availability: InStock

Numer artykułu:

WINTER-IT-299202

Gyártó: CYBERPOWER

W magazynie

Poziomy zapasów

Magazyn sklepu internetowego Winterthur Medical - W00 W magazynie

2 255,24 zł

Punkty uzyskane po dokonaniu zakupu: 11,28 zł

Szczegóły

GENERAL

Phase

Single Phase

Form Factor

Tower

UPS Topology

Online Double Conversion

Energy Saving Technology

Online ECO Mode Efficiency > 95%

Active PFC Compatibility

Yes

INPUT

Generator Compatibility

Yes

Nominal Input Voltage ( Vac )

230 ± 10%

Input Voltage Range ( Vac )

160 ~ 300

Adjustable Voltage Range ( Vac )

0~50% Load for 110 ~ 300 Vac

0~60% Load for 120 ~ 300 Vac

0~80% Load for 140 ~ 300 Vac

0~100% Load for 160 ~ 300 Vac

Input Frequency ( Hz )

50 ± 10

60 ± 10

Input Frequency Detection

Auto-sensing

Rated Input Current ( A )

4.5

Input Power Factor

0.98

Input Connector Type

IEC C14

Detachable Power Cord Plug Type

Schuko x 1

Power Cord Length (ft.)

Power Cord Length (m.)

1.5

OUTPUT

Capacity (VA)

1000

Capacity (Watts)

900

On Battery Waveform

Pure Sine Wave

On Battery Voltage(s) ( Vac )

208 ± 1%

220 ± 1%

230 ± 1%

240 ± 1%

Output Voltage Setting

Configurable

On Battery Frequency ( Hz )

50 ± 0.5%

60 ± 0.5%

Output Frequency Setting

Configurable

Power Factor

0.9

ECO Mode Voltage Tolerance

± 15 %

Overload Protection

Internal Current Limiting, Circuit Breaker, Fuse

Overload Protection (Line Mode)

110~120% Load for 1 min, >120% Load Immediately

Overload Protection (Battery Mode)

110~120% Load for 10 sec, >120% Load Immediately

Overload Protection (Bypass Mode)

>130% Load Immediately

Crest Factor

3 : 1

Harmonic Distortion (Linear Load)

THD<3%

Harmonic Distortion (Non-linear Load)

THD<5%

Internal Bypass

Automatic Bypass, Manual Bypass

Outlet(s) - Total

Outlet Type

Schuko x 2
IEC C13 x 1

Outlet(s) - Battery & Surge Protected

Typical Transfer Time ( ms )

BATTERY

Runtime at Half Load ( min )

Runtime at Full Load ( min )

Typical Recharge Time ( Hours )

Maximum Charging Current ( A )

1.5

Start On Battery

Yes

Smart Battery Management (SBM)

Yes

User-replaceable

Battery Type

Sealed Lead-acid

Single Battery Capacity ( AH )

12 V 9 AH

Compatible Extended Battery Module (EBM)

BPSE24V40A

Max. EBM Quantity ( pcs )

SURGE PROTECTION & FILTERING

Surge Suppression ( Joules )

345

EMI/RFI Filtration

Yes

MANAGEMENT & COMMUNICATIONS

LCD Panel

Yes

Color LCD

Yes

LCD Information Display

Operation Type, Power Status, Battery Status, Load Status, Fault & Warning, Other Information, Event & Log

LCD Setting & Control

Mode Setting, Alarm Setting, Input & Output, Battery Setting

HID Compliant USB Port(s)

Emergency Power Off (EPO) Port

Yes

Audible Alarms

Battery Mode, Low Battery, Overload, Overcharge, Overheat, UPS Fault, Replace Battery

Management Cable ( pcs )

USB Cable x1

Power Management Software

PowerPanel® Business (Recommended)

SNMP/HTTP Remote Monitoring

Yes - with optional RMCARD205

PHYSICAL

Enclosure Construction

Metal

Color

Black

PHYSICAL SIZE - UPS MODULE

Dimensions (WxHxD) (in.)

5.5 x 7.5 x 12.9

Dimensions (WxHxD) (mm.)

140 x 191 x 327

Weight (lbs.)

20.6

Weight (kg.)

9.4

ENVIRONMENTAL

Operating Temperature (°F)

32 ~ 104

Operating Temperature (°C)

0 ~ 40

Operating Relative Humidity (Non-condensing) ( % )

20 ~ 90

Operating Elevation ( feet/meters )

0-4,921 feet (0-1,500 meters)

Storage Temperature (°F)

-4 ~ 122

Storage Temperature (°C)

-20 ~ 50

Storage Relative Humidity (Non-condensing) ( % )

10 ~ 90

Storage Elevation ( feet/meters )

0-4,921 feet (0-1,500 meters)

Online Thermal Dissipation ( BTU/hr )

458

Variable Speed Fans

20 steps automatically

CERTIFICATIONS

Certifications

RoHS

Yes

Oferty pakietowe

Dane

Listaár:

137 541 HUF

Gyártó:

CYBERPOWER

Gyártói cikkszám:

OLS1000EA-DE

EAN:

4711027790190

Garancia:

24 hónap

EAN:

4711027790190

Rack-be szerelhető:

Nincs

Teljesítmény VA:

1000

Kapcsolási mód:

Online

Beépített adatvonal-védelem:

Van

KSH szám:

8504408390

Garancia (hónap):

Termék gyártója:

CYBERPOWER
