| PERFORMANCE |
| Display Size |
27" |
| View Area |
596.7x335.7 mm |
| Panel |
In-Plane Switching |
| Backlight |
WLED |
| Aspect Ratio |
16:9 |
| Resolution |
3840x2160(2D), 1920x2160(3D) |
| Pixel Pitch |
0.155x0.155 mm |
| Dot / Pixel Per Inch |
163 dpi |
| View Angle (H / V) |
178°/178°(2D), 20°/20°(3D) |
| Response Time |
4ms (Extreme mode) / 6ms (Normal mode) |
| Color Support |
16.7 Million |
| Refresh Rate |
60Hz |
| Brightness |
310 cd/m2 |
| Contrast Ratio |
1200:1 |
| Color Gamut |
100% sRGB, 99% Adobe® RGB, 99% DCI-P3, 100% BT.709, 83% BT.2020 |
| Screen Surface Treatment |
Anti-glare |
| Curvature |
None |
| Camera |
Modular Camera Support |
| Microphone |
None |
| Speakers |
5Wx2 |
| Power Consumption (Typical / Maximum) |
43.8W / 246W |
| Power Adapter |
Integrated |
| Touchscreen |
None |
| Smart System |
None |
| DESIGN |
| Stand |
Tilt, Swivel, Pivot, Height Adjust Stand |
| Case Color |
Raven Black |
| Side Bezel Width |
8 mm |
| Mounting |
Supports VESA mount 100 x 100 mm |
| ThinkCentre M Series Support |
Tiny, Nano Support |
| Dimensions (WxDxH) |
- Lowest Position | 614.8 x 222.7 x 413 mm (24.2 x 8.77 x 16.26 inches)
- Highest Position | 614.8 x 222.7 x 568 mm (24.2 x 8.77 x 22.36 inches)
- Head Only | 614.8 x 72.3 x 390 mm (24.2 x 2.85 x 15.35 inches)
|
| Packaging Dimensions (WxDxH) |
720 x 165 x 520 mm (28.35 x 6.5 x 20.47 inches) |
| Weight |
- Monitor With Stand | 8.9 kg (19.6 lbs)
- Monitor Head Only | 6.6 kg (14.6 lbs)
|
| Packaging Weight |
12.4 kg (27.3 lbs) |
| CONNECTIVITY |
| USB Port |
1x USB-C® 3.2 Gen 1 (DP 1.4 Alt Mode, up to 100W PD, USB upstream), 4x USB 3.2 Gen 1, 1x USB-C 3.2 Gen 1 (15W PD) |
| Video Connector |
2x HDMI® 2.1 TMDS, 1x DP 1.4, 1x USB-C® 3.2 Gen 1 (DP 1.4 Alt Mode) |
| Network Connectivity |
1x RJ45, Ethernet (10M/100M/1000M) |
| SERVICE |
| Base Warranty |
3-year |
| CERTIFICATIONS |
| Environmental Certification |
RoHS, EU Energy Efficiency Level (Level-G) |
| Ergonomic Certification |
TÜV Rheinland® Eye Comfort |
| Sync Technology |
None |
| Special Features |
- HDR Compliance (HDR10 Decoding)
- Factory Calibration: Avg. Delta E<1 (for DCI-P3, Adobe® RGB and sRGB)
- 3D Explorer, available from Lenovo® Accessories and Display Manager (ThinkColour) Lenovo Accessories and Display Manager supports Windows® 10 & 11, Mac OS, and Windows On Arm (functions vary across systems)
- 3D Master (3D viewing App), Design Engine, 2D-to-3D Converter, Plugins, SDK
- Smart Power The Smart Power function intelligently detects overall power consumption and dynamically manages the power delivery to each device
|
| 3D Features |
- 2D/3D Switchable
- 3D resolution: 1920 x 2160
- Environmental conditions: 0 lx - 1000 lx
- Eye tracking support
- Number of viewers: 1
- Optimal viewing angle: -20° to +20° horizontal, -20° to +20° vertical
- Optimal viewing distance: 60 - 100 cm
- Recommended 3D viewing distance: 70 - 90 cm
- Minimal PC Requirements: CPU: i5 7400/3.00GHz Graphic: NVIDIA® GeForce GTX 1050 (or AMD, Intel® graphics card with equivalent performance) Operating system: Windows® 10 (64-bit) Memory: 8GB DDR5 Storage: 50GB available space
- Supported third-party software: Microsoft® 365, PTC Creo, Autodesk 3ds Max, Autodesk VRED, Autodesk Maya, Trimble SketchUp Pro, Blender, Lumiscaphe Patchwork 3D, Dassault Systems Deltagen, Unity, C++ & Unreal (via SDK)
|
| SOFTWARE |
| Operating System |
Support Windows® 10, Windows 11 |
| ACCESSORIES |
| Video Cables |
HDMI® Cable (1.8 m), DP Cable (1.8m), USB-C® to USB-A Cable (1.8m), USB-C to USB-C Gen 2 Cable (1.5m) |
